PD3122

The module is an intelligent module, provided with 16 input/output channels for 24 VDC and an internal user programmable Calculator for local control. Each channel has pulse and one-shot output, current measuring and overload protection. Each input has pulse counting, max 50 Hz and measures operating time. All outputs have test of single as well as double feed-back signals.



Supply voltage: 24 V DC.

Loading...

ORDERING

Picture Part. No. Name Price Quantity
600532 DKK 4,980.00

PRODUCT DESCRIPTION

The module is an intelligent module, provided with 16 input/output channels for 24 VDC and an internal user programmable Calculator for local control. Each channel has pulse and one-shot output, current measuring and overload protection. Each input has pulse counting, max 50 Hz and measures operating time. All outputs have test of single as well as double feed-back signals.



Supply voltage: 24 V DC.
